Heatit Z-Temp2 White

Z-Wave battery operated temperature sensor

Product is not available for order.
Log in to get your personal prices. Register Login
Heatit Z-Temp2 is a battery-operated thermostat designed for use with waterbased heating systems. Used in combination with the Heatit Z-Water you can control your heating system with a Z-Wave primary controller/gateway. This is a “wire-free” solution, saving both time and money. All communication between the Heatit Z-Temp2 and the controlled device is 100% wireless.

Heatit Z-Temp2 has SmartStart. This feature allows the user to include all devices with SmartStart by scanning the QR codes on the devices. On startup all the devices will automatically be included in the gateway (requires SmartStart compability). This saves the installer a lot of work.

Heatit Z-Temp may be associated with the Heatit Z-Relay or another Z-Wave relay in order to control many types of heating solutions. The Heatit Z-Temp2 is an excellent choice when restoring or remodeling existing buildings, as it is easy to install without any need for wiring. We recommend using several 230VAC units to strengthen the mesh network.

Please note that this unit equipped with firmware
version 1.1 does NOT include cooling
Download User Manual FW 1.1

Firmware version 1.2 includes cooling
Download User Manual FW 1.2

You can not upgrade from Firmware version 1.1 to 1.2 through OTA on this unit.

GTIN: 7071236015307 4512666
  • Z-Wave thermostat for controlling external relay
  • Internal room sensor
  • Humidity sensor
  • Proximity sensor to turn on the display
  • SmartStart
  • Automatic brightness control
  • Firmware update (OTA)
  • Weekly program/setback via gateway
  • 5 associations
  • Lock mode/child lock
  • Supports encryption modes S0, S2 Authenticated Class, S2 Unauthenticated Class
Technical data
  • IOT Protocol: Z-Wave - 868.4 MHz (EU)
  • Voltage: Batteries 3 x AA
  • Max installation temperature (°C): 40
  • Min installation temperature (°C): 2
  • Min. working temperature (°C): 0
  • Temperature interval: External room sensor 5°C - 40°C
  • Hysteresis: 0,3°C to 3,0°C (default hysteresis 0,5°C)
  • Protection grade (IP): IP 21
  • Certifications: Z-Wave Plus v2
  • Dimensions (LxHxW): 25x85x85mm
  • Declarations: CE
  • International standard: CE, EN 62368-1:2014+A11:2017, EN 62479:2010, ETSI EN 300 220-1 V3.1.1 (2017-02), ETSI EN 300 220-2 V3.2.1 (2018-06), ETSI EN 301 489-1 V 2.2.3 (2009-11), ETSI EN 301 489-3 V2.1.1 (2019-03), RED 2014/53/EU, RoHS 2011/65/EU
  • Signal range radio frequency (max no. meters): 40
  • SDK: 6.81.03
  • Max ambient humidity (%RH): 85% RF
  • Max regulating temperature (ºC): 40
  • Max temperature without load (°C): 40
  • Max temperature with load (°C): 40
  • Model type: Termostat
  • Product height (mm): 85
  • Product length (mm): 25
  • Product weight (gram): 174
  • Product width (mm): 85
  • IOT Chip type: Z-Wave 700 chip
  • Z-Wave encryption mode: S0, S2 Authenticated Class, S2 Unauthenticated Class
+ Show more (18)
- Show less
Stock Info
Not in stock
The product is located in Sweden, and will be shipped from Sweden.

VAT applicable for personal use. See Pricing-section.
Shipping cost will apply.
The device is maintenance-free, but must never be covered.
