An innovative thermostat incorporating Z-Wave

technology for regulating electric floor heating.

Functions

Heatit Z-Wave thermostat



Heatit Z-Wave is an electronic thermostat for flush mounting in a standard wall box. The thermostat has a built-in Z-Wave chip that can be connected to Home Automation systems like Fibaro, POPP, Vera, Zipato and others.



The display will show the ambient temperature in the floor. The thermostat is equipped with sensitive cap sense buttons. By lightly pressing the buttons, the display will show the set value.



Heatit Z-Wave is equipped with a single-pole switch. The thermostat can handle loads up to 16A/3600W at 230V. If the load is greater than this, the thermostat needs to be connected to a contactor. It can be used with two external temperature sensors. The thermostat has the capacity of up to 8 associations (relays etc.)

-

Floor sensor

-

External room sensor

-

Temperature limiter

-

Power regulator

-

Z-Wave chip 500-series

-

Weekly program via gateway

-

Setback mode via gateway or pilot wire

-

7-segment white LCD-screen

-

Can be used in connection with different NTC sensors

-

Lock mode/Child lock

-

Backlight

-

Calibration

-

Setback temperature in association with door/window sensor

-

8 scenarios

Dimensions

Technical data

Rated voltage:

230V 50/60Hz

Max. load:

3600W (resistive load)

750W self-limiting heating cables

Max. current:

16A

Power usage:

1,5W

Power regulator:

Time cycle 0-30 min

Min/max inst. temp:

-200 C to 400 C

Min/max oper.temp:

50 C to 400 C

Temperature intervals:

Floor sensor:

50C to 400C



External room sensor: 50C to 400C

Hysteresis:

0,30C to 3,00C

Default hysteresis:

0,50C

Sensor values:

00C 29,1 kOhm



100C 18,6 kOhm



150C 15,1 kOhm



200C 12,2 kOhm



250C 10,0 kOhm

Switch:

IP class:

Single-pole

IP21



Connection clamps

Included equipment

  • Floor sensor 4mm. Length: 3 m

Colors

  • Use 1,5 mm² or 2,5 mm² according to power need.

These are the meaning of error-codes given by the Heatit Thermostats:

Er1

= Internal error, irreparable. Replace the thermostat with a new unit.

Er2

= error related to Z-Wave

Er3

= Internal error, irreparable. Replace the thermostat with a new unit.

Er4

= error related to floor sensor. The floor sensor are usually either misssing or broken.

Er5

= error related to external sensor. The sensor are usually either missing or broken.



ART.NO.

PRODUCT

COLOR

5430499

Heatit Z-Wave thermostat

White RAL 9003

5430498

Heatit Z-Wave thermostat

Black RAL 9011

9930446

Plastic kit for Heatit Z-Wave thermostat

Black RAL 9011

5430311

Frame for Heatit

White RAL 9003

5430312

Frame for Heatit

Black RAL 9011

5430497

Cable for software update on thermostat



5430108

Heatit floor sensor Ø3 mm, 6 m NTC 10 kOhm



5430109

Heatit floor sensor Ø4 mm, 3m NTC 10 kOhm



5430129

Heatit ext. room sensor, mini NTC 10 kOhm



5430128

External room sensor NTC 10 kOhm
