Heatit ZM Thermostat is an electronic thermostat for electrical underfloor heating designed for inwall installations. The thermostat allows you to control your electrical heating through your Z-Wave network.
The module is equipped with a 16A relay. The thermostat requires you to connect an external wired sensor, which is included.
Heatit ZM Thermostat has active power metering and it gives you real time information about your power consumption.
Supports encryption mode: S0, S2 Authenticated Class, S2 Unauthenticated Class
Technical data
IOT Protocol:Z-Wave - 868.4 MHz (EU)
Voltage:230VAC 50Hz
Max load (Watt - resistive load):3600
Own power usage (watt):1
Hysteresis:0,3 to 3,0 (default hysteresis 0,5)
Switch type:One-pole switch
Compatible NTC-sensors (Ω @ 25°C):10
Protection grade (IP):IP20
Alternate IoT-communication procols:No alternative communication protocols
Ambient humidity (RH non-condensing %):10-85
Ambient temperature range in storage (°C):-30-70
Total gross effect (W):3600
Declarations:RoHS, Reach
International standard:EN 60669-2-1/A12:2010, RoHS 2002/95/EC, IEC 965-2-1, ETSI EN 301 489-3 V2.1.1(2017-03), ETSI EN 300 220-2 V3.1.1 (2017-02), EN 62479:2010, EN 60669-2-5:2016, EN 60669-2-1:2004 + A1:2009, WEE 2002/96/EC, CE, Z-Wave Plus
Signal range radio frequency (max no. meters):40
Max connection dimension (mm²):2,5
IOT Chip type:Z-Wave 700 chip
Push buttons:1
Z-Wave encryption mode:S0, S2 Unauthenticated Class, S2 Authenticated Class
+ Show more (12)
- Show less
Stock Info
Not in stock
The product is located in Sweden, and will be shipped from Sweden.
VAT applicable for personal use. See Pricing-section.
Shipping cost will apply.
Maintenance
The device is maintenance-free. Indoor use only.
Dealers / Where to buy
Based on your location Heatit Controls does not have a reseller or distributor in your country. You can take a look at our list of resellers and distributors on the Where to buy section or you can purchase directly from us in Sweden on this site.
Pricing
Base price without VAT: € 50.00 Base price subjective to 0% VAT: € 50.00
